導軌作為各類機械運動和門窗系統的導向結構，其平行度直接影響設備運行的穩定性、順暢度與使用壽命。無論是卷簾門、電梯轎廂還是工業流水線的導軌，平行安裝調整都需要精準控制間距誤差、垂直度與水平度，任何細微偏差都可能導致運行卡頓、局部磨損加劇或噪音增大。以下從準備工作、分步調整、校驗方法到常見問題處理，系統解析導軌平行安裝的調整邏輯與實操技巧。

　　As a guiding structure for various mechanical movements and door and window systems, the parallelism of guide rails directly affects the stability, smoothness, and service life of equipment operation. Whether it is roller shutter doors, elevator cars, or industrial assembly line guides, parallel installation and adjustment require precise control of spacing errors, verticality, and levelness. Any slight deviation may lead to operational lag, increased local wear, or increased noise. The following provides a systematic analysis of the adjustment logic and practical skills for parallel installation of guide rails, from preparation work, step-by-step adjustment, verification methods to common problem handling.

　　調整前的準備工作與工具選擇

　　Preparation and tool selection before adjustment

　　導軌平行安裝調整前，需先完成基礎檢查與工具準備。首要任務是確認安裝基面的平整度，使用 2 米靠尺檢測地面或墻面的凹凸程度，若誤差超過 3mm/m，需先用水泥砂漿或墊片找平 —— 不平整的基面會直接導致導軌安裝后產生應力，影響平行度的長期穩定性。對于墻面安裝的導軌（如卷簾門、推拉門），還需檢查墻體的垂直度，避免因墻體傾斜造成導軌 “被動歪斜”。

　　Before adjusting the parallel installation of the guide rail, it is necessary to complete the foundation inspection and tool preparation. The primary task is to confirm the flatness of the installation base surface, using a 2-meter ruler to detect the unevenness of the ground or wall surface. If the error exceeds 3mm/m, it is necessary to first level it with cement mortar or gaskets - an uneven base surface will directly cause stress after the installation of the guide rail, affecting the long-term stability of parallelism. For wall mounted guide rails (such as rolling shutter doors and sliding doors), it is also necessary to check the verticality of the wall to avoid "passive tilting" of the guide rails caused by wall inclination.

　　工具選擇需兼顧精度與實用性。核心工具包括：2 米激光水平儀（精度 ±0.5mm/m）用于校準水平與垂直；5 米鋼卷尺（誤差≤1mm）用于測量間距；線墜（重量≥500g）輔助檢測垂直度；塞尺（0.02-1mm 規格）用于測量縫隙偏差；以及一組不同厚度的金屬墊片（0.5mm、1mm、2mm、5mm）用于微調高度。此外，還需準備木工鉛筆、記號筆、手電鉆與膨脹螺栓，確保調整后能快速固定。

　　Tool selection should balance accuracy and practicality. The core tools include a 2-meter laser level (accuracy ± 0.5mm/m) for calibrating horizontal and vertical alignment; 5-meter steel tape measure (error ≤ 1mm) is used to measure spacing; Use a plumb bob (weighing ≥ 500g) to assist in detecting verticality; A feeler gauge (0.02-1mm specification) is used to measure gap deviation; And a set of metal pads of different thicknesses (0.5mm, 1mm, 2mm, 5mm) are used to fine tune the height. In addition, woodworking pencils, markers, electric drills, and expansion bolts need to be prepared to ensure quick fixation after adjustment.

　　環境因素也需提前考量。溫度變化會導致金屬導軌熱脹冷縮，調整應避開極端高溫或低溫時段，若在冬季施工，需預留 0.1-0.2mm/m 的溫度補償間隙；潮濕環境下，調整前需清理導軌表面的銹跡與油污，防止墊片打滑影響調整精度。

　　Environmental factors also need to be considered in advance. Temperature changes can cause thermal expansion and contraction of metal guide rails. Adjustments should avoid extreme high or low temperature periods. If construction is carried out in winter, a temperature compensation gap of 0.1-0.2mm/m should be reserved; In humid environments, it is necessary to clean the rust and oil stains on the surface of the guide rail before adjustment to prevent the gasket from slipping and affecting the adjustment accuracy.

　　基準導軌的設定與初步固定

　　Setting and preliminary fixation of reference guide rail

　　平行安裝的關鍵是先確立基準導軌，以此為參照調整另一根導軌。選擇其中一根導軌作為基準時，需優先考慮安裝面的穩定性 —— 若兩側墻面或地面平整度存在差異，應選擇基面更平整的一側作為基準。基準導軌的固定需分兩步：先用臨時支架將導軌初步固定，確保其頂面與設計標高一致，再用激光水平儀校準其垂直度（偏差需≤1mm/m），垂直度調整可通過在導軌底部加減墊片實現，每調整 1mm 垂直度約需增減對應厚度的墊片。

　　The key to parallel installation is to first establish a reference rail, which can be used as a reference to adjust the other rail. When selecting one of the guide rails as the reference, priority should be given to the stability of the installation surface - if there is a difference in the flatness of the walls or floors on both sides, the side with a flatter base surface should be selected as the reference. The fixation of the reference guide rail needs to be divided into two steps: first, use a temporary bracket to preliminarily fix the guide rail to ensure that its top surface is consistent with the design elevation, and then use a laser level to calibrate its verticality (deviation should be ≤ 1mm/m). The verticality adjustment can be achieved by adding or removing shims at the bottom of the guide rail. For every 1mm verticality adjustment, the corresponding thickness of shims needs to be added or removed.

　　基準導軌的水平度調整同樣重要。對于地面安裝的導軌（如流水線軌道），將激光水平儀投射到導軌頂面，若顯示存在傾斜，松開臨時固定螺栓，在較低一側的支架下增加墊片，直整根導軌的水平誤差控制在 0.5mm/m 以內。墻面安裝的垂直導軌（如卷簾門導軌）則需用線墜檢測全高垂直度，從頂部到底部的偏差應≤3mm（針對 3 米長導軌），調整時通過擰動膨脹螺栓的松緊度，配合撬棍微調導軌位置，待線墜與導軌側面的間隙均勻后，擰緊緊固螺栓但不擰死，為后續微調預留空間。

　　The horizontal adjustment of the reference rail is equally important. For ground mounted rails (such as assembly line tracks), project the laser level onto the top surface of the rail. If there is a tilt displayed, loosen the temporary fixing bolts and add shims under the lower bracket until the horizontal error of the entire rail is controlled within 0.5mm/m. Vertical guide rails installed on the wall (such as roller shutter door guide rails) need to be checked for full height verticality with a plumb bob. The deviation from top to bottom should be ≤ 3mm (for 3-meter-long guide rails). When adjusting, adjust the position of the guide rail by tightening the expansion bolt and using a pry bar to fine tune it. After the gap between the plumb bob and the side of the guide rail is uniform, tighten the fastening bolt but do not tighten it to reserve space for subsequent fine adjustments.

　　水平與垂直方向的平行度調整

　　Horizontal and vertical parallelism adjustment

　　基準導軌固定后，即可進行第二根導軌的平行度調整，核心是控制 “三維偏差”：水平間距偏差、垂直高度差與立面垂直度偏差。水平間距調整需在導軌兩端及中點三個位置測量，以卷簾門導軌為例，假設設計間距為 800mm，需確保兩端測量值均為 800mm±1mm，中點測量值與兩端的差值≤0.5mm—— 若中點間距偏大，說明導軌中部向外彎曲，需在中部支架處向內施加微調力；若間距偏小，則需向外頂推，調整時可用 C 型夾配合木塊緩慢施力，避免用力過猛導致導軌變形。

　　After fixing the reference guide rail, the parallelism adjustment of the second guide rail can be carried out, with the core being to control the "three-dimensional deviation": horizontal spacing deviation, vertical height difference, and vertical deviation of the facade. Horizontal spacing adjustment needs to be measured at three positions: the two ends and the midpoint of the guide rail. Taking the roller shutter door guide rail as an example, assuming the design spacing is 800mm, it is necessary to ensure that the measured values at both ends are 800mm ± 1mm, and the difference between the midpoint measurement value and the two ends is ≤ 0.5mm. If the midpoint spacing is too large, it indicates that the middle of the guide rail is bent outward, and a fine adjustment force needs to be applied inward at the middle bracket; If the spacing is too small, it needs to be pushed outward. When adjusting, a C-clip can be used to slowly apply force with a wooden block to avoid excessive force causing deformation of the guide rail.

　　垂直方向的平行度控制需同步關注高度差與垂直度。使用激光水平儀在兩根導軌的同一高度投射水平線，測量導軌頂面與水平線的距離，兩端高度差應≤1mm，否則需通過底部墊片調整。垂直度調整需保證兩根導軌的 “傾斜方向一致”，用激光水平儀分別檢測兩根導軌的垂直度，若基準導軌垂直度為 0.5mm/m（向左側傾斜），則第二根導軌的垂直度需控制在 0.5mm/m±0.3mm/m 且傾斜方向相同，避免形成 “八字形” 或 “倒八字形” 偏差 —— 這種對稱偏差看似間距均勻，實則會導致運動部件（如門體、滑塊）兩側受力不均。

　　The control of parallelism in the vertical direction requires simultaneous attention to the height difference and perpendicularity. Use a laser level to project a horizontal line at the same height on two guide rails, and measure the distance between the top surface of the guide rail and the horizontal line. The height difference between the two ends should be ≤ 1mm, otherwise it needs to be adjusted through the bottom gasket. The verticality adjustment needs to ensure that the "tilt direction" of the two guide rails is consistent. Use a laser level to detect the verticality of the two guide rails separately. If the verticality of the reference guide rail is 0.5mm/m (tilted to the left), then the verticality of the second guide rail should be controlled within 0.5mm/m ± 0.3mm/m and the tilt direction should be the same to avoid the formation of a "figure eight" or "inverted figure eight" deviation - this symmetrical deviation may seem evenly spaced, but it can actually cause uneven stress on both sides of moving parts (such as doors and sliders).

　　對于長于 6 米的導軌，需采用分段調整法。每 3 米設置一個調整點，先固定兩端，再調整中間段，避免因?qū)к壸陨頁隙扔绊懻w平行度。調整過程中需多次往返測量，因為某一部位的調整可能引發其他部位的連鎖變化，尤其是剛性較差的薄壁導軌，需耐心微調全段偏差趨于一致。

　　For guide rails longer than 6 meters, segmented adjustment method should be used. Set an adjustment point every 3 meters, fix both ends first, and then adjust the middle section to avoid affecting the overall parallelism due to the deflection of the guide rail itself. Multiple back and forth measurements are required during the adjustment process, as adjusting one part may cause chain changes in other parts, especially for thin-walled guide rails with poor rigidity, which need to be patiently fine tuned until the deviation of the entire section tends to be consistent.
